Straight Strips

Straight strip metal channel industrial brushes are the most common of the metal channel industrial brushes that Carolina Brush manufactures. Our straight strip brushes can be formed into cup brushes, disk brushes (external and inverted), helixed/helical strips, arcs or curved industrial brushes.

Straight strips are used individually or in multiples and may be mounted on flat surfaces or on cylinders. Typical applications for straight strips include splash curtains, drag or sweep type conveyor cleaners, tensioning devices, static dissipating, paint booth and conveyor-side seals and product hold-down devices.

METAL CHANNEL INFORMATION

METAL CHANNEL SIZE	METAL CHANNEL Width X Height (Approximate)	CENTER WIRE DIAMETER	ALUMINUM CHANNEL	GALVANIZED STEEL CHANNEL	STAINLESS STEEL CHANNEL	FLAT	OVAL
#2	0.094" X 0.110"	.025" dia		XXX		XXX
#2.5	0.125" X 0.125"	.031" dia		XXX	XXX	XXX
#3	0.156" X 0.156"	.041" dia		XXX	XXX	XXX
#4	0.187" X 0.187"	.045" dia	XXX	XXX	XXX	XXX
#5	0.218" X 0.250"	.062" dia		XXX	XXX	XXX	XXX
#6	0.234" X 0.343"	.062" dia		XXX		XXX	XXX
#7	0.312" X 0.312"	.080" dia	XXX	XXX	XXX	XXX	XXX
#8	0.328" X 0.375"	.080" dia		XXX		XXX
#10	0.437" X 0.437"	.105" dia		XXX	XXX	XXX
